Product details
Please check with your carrier for network compatibility before purchasing.
Bands
5G: n1 (2100), n2 (1900 PCS), n3 (1800), n5 (850), n7 (2600), n8 (900), n12 (700), n20 (800), n25 (1900), n26 (850), n28b (700), n28a (700), n38 (2600), n40 (2300), n41 (2500), n66 (1700), n75 (1500), n77 (3700), n78 (3500)
4G LTE: B1 (2100), B2 (1900), B3 (1800), B4 (1700/2100 AWS 1), B5 (850), B7 (2600), B8 (900), B12 (700), B13 (700), B17 (700), B18 (800), B19 (800), B20 (800), B25 (1900+), B26 (850), B28b (700), B28a (700), B32 (1500), B38 (TDD 2600), B39 (TDD 1900), B40 (TDD 2300), B41 (TDD 2500), B66 (1700/2100)
Launch
-
Announced: July 22, 2026
-
Status: Available. Released July 22, 2026
Body
-
Dimensions: Unfolded: 166.9 x 75.4 x 6.1 mm; Folded: 85.7 x 75.4 x 13.1 mm
-
Weight: 180 g
-
Build: Plastic front (unfolded), Gorilla Glass Victus 2 back, Armor Aluminum frame
-
SIM: Nano-SIM + eSIM + eSIM (up to 2 active SIMs at a time)
-
Protection: IP48 dust and water resistance (dust protection against particles larger than 1 mm; water immersion up to 1.5 m for 30 minutes)
Display
-
Main Display: 6.9-inch Foldable Dynamic LTPO AMOLED 2X, 120Hz, HDR10+, 3000 nits peak brightness
-
Resolution: 1080 x 2520 pixels, 21:9 aspect ratio, approximately 400 PPI
-
Cover Display: 4.1-inch Super AMOLED, 120Hz, 3000 nits peak brightness
-
Cover Resolution: 948 x 1048 pixels, approximately 342 PPI
-
Cover Protection: Gorilla Glass Victus 2
Platform
-
Operating System: Android 17, One UI 9, up to 7 major Android OS upgrades
-
Chipset (US/Canada/China): Qualcomm Snapdragon 8 Elite Gen 5 (3 nm)
-
Chipset (Rest of World): Samsung Exynos 2600 (2 nm)
-
CPU (US/Canada/China): Octa-core (2x 4.74 GHz Oryon V3 Phoenix L + 6x 3.62 GHz Oryon V3 Phoenix M)
-
CPU (Rest of World): 10-core (1x 3.80 GHz C1-Ultra + 3x 3.25 GHz C1-Pro + 6x 2.75 GHz C1-Pro)
-
GPU (US/Canada/China): Adreno 840 (1.3 GHz)
-
GPU (Rest of World): Xclipse 960
Memory & Storage
-
Card Slot: No
-
Internal Storage: 256GB with 12GB RAM; 512GB with 12GB RAM
-
Storage Type: UFS 4.x
Main Camera
-
Dual Camera System: 50MP main camera, f/1.8 aperture, 23mm wide, 1/1.56-inch sensor, 1.0µm pixels, Dual Pixel PDAF, OIS; 12MP ultrawide camera, f/2.2 aperture, 13mm, 123° field of view, 1/3.2-inch sensor, 1.12µm pixels
-
Features: LED flash, HDR, panorama
-
Video Recording: 4K at 30/60fps, 1080p at 60/120/240fps, HDR10+
Selfie Camera
-
Camera: 10MP, f/2.2 aperture, 23mm wide, 1/3.52-inch sensor, 1.12µm pixels
-
Features: HDR
-
Video Recording: 4K at 30/60fps
Sound
-
Loudspeaker: Yes, stereo speakers
-
3.5mm Headphone Jack: No
-
Audio: High-bitrate audio support
Communications
-
WLAN: Wi-Fi 802.11 a/b/g/n/ac/6E/7, tri-band, Wi-Fi Direct
-
Bluetooth: 5.4, A2DP, LE
-
Positioning: GPS, GALILEO, GLONASS, BDS
-
NFC: Yes
-
Radio: No
-
USB: USB Type-C 3.2, OTG
Features
-
Sensors: Side-mounted fingerprint sensor, accelerometer, gyroscope, proximity sensor, compass, barometer
-
Additional Features: Samsung DeX desktop experience support
Battery
-
Type: 4300mAh Si/C Li-Ion battery
-
Wired Charging: 25W, QC 2.0, up to 55% in 30 minutes
-
Wireless Charging: 15W
-
Reverse Wireless Charging: 4.5W
Miscellaneous
-
Available Colors: Graphite, Cream, Pink, Mint
-
Model Number: SM-F776W
